Solar Panels


PV Modules

A photovoltaic module is a packaged interconnected assembly of photovoltaic cells, which converts sunlight into electrical energy. Solar module of Mono/Poly crystalline is considered. The modules being offered are IEC 61215 / IS 14286, IEC 61730 Part 1 and 2 and IEC 61701 compliance with standards as specified by Ministry of New and Renewable Energy (MNRE).

Main Characteristics Of Our PV Modules

  • Manufactured according to international quality and Environment Management System.
  • High efficiency crystalline silicon solar cells
  • High transmission Iow iron tempered glass, strong mechanical resistance
  • Anti-ageing EVA and excellent anti-climate back sheet
  • Anodized aluminum frame improves load resistance capabilities for heavy wind loads.
  • Standard waterproof junction box
  • High endurance to different weather
  • Good and friendly package with less transportation and storage space.
Front cover (material / thickness) low-iron tempered glass / 3.2mm
Cell (quantity / material / number of busbars/Cell Efficiency) 60 / multicrystalline silicon / 3/ 17% Eff or more
Back Sheet TPT Backsheet (Multi laminated film).
Encapsulant (material) ethylene vinyl acetate (EVA) ethylene vinyl acetate (EVA)
Frame (material / color / anodization color /edge sealing) anodized aluminum alloy / silver / clear / silicone or tape
Junction box (protection degree) ≥ IP65
